Specifications
| NOMINAL SIZE (inch) | Approx ID (inch) | Approx OD (inch) | Max Working Pressure @ 72° F (psi) | Design Burst Pressure @ 72° F (psi) | Approx Weight (lbs/roll) |
|---|---|---|---|---|---|
| 3/16 | 0.19291 | 0.40551 | 250 | 1,000 | 16.4 |
| 1/4 | 33/128 | 15/32 | 250 | 1,000 | 19.5 |
| 5/16 | 0.31496 | 0.53543 | 200 | 1,000 | 24.7 |
| 3/8 | 49/128 | 5/8 | 200 | 800 | 32 |
| 1/2 | 33/64 | 3/4 | 200 | 800 | 38 |
| 5/8 | 81/128 | 7/8 | 200 | 800 | 45 |
| 3/4 | 49/64 | 1-1/32 | 175 | 600 | 61 |
| 1 | 1 | 1-5/16 | 125 | 500 | 32 |
| 1-1/4 | 1-1/4 | 1-3/4 | 100 | 400 | 63 |
| 1-1/2 | 1-1/2 | 2 | 75 | 300 | 74 |
| 2 | 2 | 2-1/2 | 75 | 300 | 95 |
