Braided EPDM Rubber Suction/Discharge Hose
APPEARANCE / CONSTRUCTION:
Black EPDM rubber tube and wall with polyester braid reinforcement; black polyethlene helix. Corrugated wall, smooth interior.
BENEFITS:
-Excellent flexibility and durability
-Higher working pressure than standard EPDM
-Good chemical resistance
GENERAL APPLICATIONS:
-Suction/discharge service for industry and agriculture
-Applications requiring the chemical resistance of EPDM rubber at higher working pressure
TEMPERATURE RANGE:
-30F TO +140F
STANDARD LENGTHS:
2″ through 4″ 100 feet
| NOMINAL SIZE (inch) | Approx OD (inch) | Rec WP @ 72° F (psi) | Vacuum Rating (in/Hg) | Rec Min Bend Radius @ 72° F (inch) | Approx Burst Pressure @ 72° F (psi) | Approx Weight (lbs/ft) |
|---|---|---|---|---|---|---|
| 1-1/2 | 2.07 | 100 | 28 | 4 | 300 | .55 |
| 2 | 2.66 | 100 | 28 | 4 | 310 | .88 |
| 3 | 3.86 | 85 | 28 | 6 | 260 | 1.48 |
| 4 | 4.87 | 70 | 28 | 8 | 210 | 2.30 |
