Specifications
NOMINAL SIZE (inch) | Approx OD (inch) | Approx WP @ 140° F (psi) | Vacuum Rating (in/Hg) | Rec Min Bend Radius @ 72° F (inch) | Approx Burst Pressure @ 72° F (psi) | Approx Weight (lbs/ft) |
---|---|---|---|---|---|---|
1-1/2 | 1.88 | 50 | 28 | 3 | 210 | .38 |
2 | 2.41 | 40 | 28 | 4 | 180 | .54 |
2-1/2 | 2.98 | 35 | 28 | 5 | 135 | .77 |
3 | 3.54 | 35 | 28 | 6 | 135 | 1.05 |
3-1/2 | 4.04 | 30 | 28 | 8 | 135 | 1.25 |
4 | 4.65 | 30 | 28 | 8 | 135 | 1.68 |
5 | 5.77 | 30 | 28 | 9 | 80 | 2.40 |
6 | 6.86 | 25 | 28 | 12 | 80 | 3.18 |
8 | 9.10 | 25 | 28 | 16 | 75 | 5.73 |
